8
Clip
Note: If there is a thin sheet
of clear plastic on the face
of the console, remove it. Key Pulse
Sensor
Incline
Control
Speed Control
Monitor Display
BATTERY INSTALLATION
The console requires two "AA" batteries (not in-
cluded). Alkaline batteries are recommended. To install
batteries, open the battery cover as shown below.
Press two batteries into the console, with the negative
(–) ends of the batteries touching the springs. Close
the battery cover, push up on the tab, and then push
the tab forward as shown. Be sure that the tab locks
into place.
STEP-BY-STEP CONSOLE OPERATION
Step onto the foot rails of the treadmill. Find the clip
attached to the key (see the drawing above), and slide
the clip onto the waistband of your clothes. Test the
clip by carefully taking a few steps backward until
the key is pulled from the console. If the key is not
pulled from the console, adjust the position of the
clip as needed. Follow the steps below and on page 9
to operate the console.
Insert the key fully into the power switch.
Inserting the key will
not turn on the display.
The display will turn on
when the ON/RESET
button is pressed or
when the walking belt
is started. (If you just
installed batteries, the display will already be on.)
1
Batteries
Battery Cover
Tab
CAUTION:
Before operating the
console, read the following precautions.
• Do not stand on the walking belt when turning
on the power.
• Always wear the clip (see the drawing above)
while operating the treadmill. When the key is
removed from the console, the walking belt will
stop.
• Adjust the speed in small increments.
• The training zones marked around the speed
control are general guidelines only. See page
14 or more information.
• To reduce the possibility of electric shock, keep
the console dry. Avoid spilling liquids on the
console and use only a sealable water bottle.
