Part identification chart – Weider WEBE13010 User Manual
Page 5
5
Refer to the drawings below to identify small parts used in assembly. The number in parentheses by each draw-
ing is the key number of the part, from the PART LIST on page 14 of this manual.
Note: Some small parts may
have been pre-attached. If a part is not in the parts bag, check to see if it has been pre-attached.
PART IDENTIFICATION CHART
M8 x 60mm Bolt (16)
M8 x 16mm Bolt (17)
3/8" x 2" Bolt (21)
3/8" Washer (18)
3/8" Nylon Locknut (19)
3/8" x 2.85" Bolt (23)
3/8" x 3/4" Bolt (22)
