Western Digital WD TV WDAVN00 - Manual (Page 2)

WD TV HD Media Player
Dimensions
Height: 1.57 in (40 mm)
Depth: 3.94 in (100 mm)
Width: 4.92 in (125 mm)
Weight: 0.67 lb (302.5 g)
Model Number
WDAVN00xx
Limited Warranty
PanAm 1 year
APAC 1 year
EMEA 2 years
Kit Contents
HD media player
Compact remote with batteries
Media converter software (Windows
® only)
Composite AV cable
AC adapter
Quick Install Guide
Product Specifications
Operating temperature: 5°C to 35°C
41° F to 95° F
Non-op. temperature: -40° C to 65° C
-40° F to 149° F
Western Digital, WD, the WD logo, and Put Your Life On It are registered trademarks in the U.S. and other countries; WD TV and My Passport are trademarks of Western Digital
Technologies, Inc. Other marks may be mentioned herein that belong to other companies. Pictures shown may vary from actual products. Not all products may be available in all
regions of the world. All product and packaging specifications subject to change without notice. The term of your limited warranty depends on the country in which your product
was purchased. Please visit our web site at support.wdc.com/warranty for the detailed terms and conditions of our limited warranty.
© 2009 Western Digital Technologies, Inc. All rights reserved.
TV and USB storage device required for multimedia viewing (not included). Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are
trademarks of Dolby Laboratories. 4178-705027-A05 June 2009
Play HD in 3 easy steps:
My Passport portable USB drive
sold separately.
Media Formats
AVI (Xvid, AVC, MPEG1/2/4, WMV9, VC-1), MPG/MPEG, VOB,
MKV (h.264, x.264, AVC, MPEG1/2/4, WMV9, VC-1), TS/TP/M2T
(MPEG1/2/4, AVC, VC-1), MP4/MOV (MPEG4, h.264), M2TS, WMV9
JPEG, GIF, TIFF, BMP, PNG
MP3, WAV/PCM/LPCM, WMA, AAC, FLAC, MKA, AIF/AIFF, OGG,
Dolby Digital, DTS
Playlist PLS, M3U, WPL
Subtitle SRT, ASS, SSA, SUB, SMI
Home
Entert
ainment
Does not support protected premium content including movie and
music downloads from iTunes ® Store, Cinema Now, Movielink ® ,
Amazon Unbox ™ , and Vongo ® .
MPEG2 MP@HL up to 1920x1080p24, 1920x1080i30 or 1280x720p60 resolution. MPEG4.2 ASP@L5 up to 1280x720p30 resolution and no support for global motion
compensation. WMV9/VC-1 MP@HL up to 1280x720p60 or 1920x1080p24 resolution. VC-1 AP@L3 up to 1920x1080i30, 1920x1080p24 or 1280x720p60 resolution. H.264 BP@
L3 up to 720x480p30 or 720x576p25 resolution. H.264 [email protected] and [email protected] up to 1920x1080p24, 1920x1080i30, or 1280x720p60 resolution. An audio receiver is required for
multi-channel surround sound digital output. Compressed RGB JPEG formats only and progressive JPEG up to 2048x2048. Single layer TIFF files only. Uncompressed BMP only.
Specific details, please refer to the user manual.
