Weider 831.159301 User Manual
Page 22
REMOVE THIS PART IDENTIFICATION CHART AND PART LIST/
EXPLODED DRAWING. SAVE THIS PART IDENTIFICATION CHART
AND PART LIST/EXPLODED DRAWING FOR FUTURE REFERENCE.
PART LIST—Model No. 831.159301
R0304A
1
2
M8 x 65mm Carriage Bolt
2
1
M6 Nylon Locknut
3
9
M8 Nylon Locknut
4
1
Base
5
1
Stabilizer
6
3
“V”-pulley
7
3
M10 x 58mm Bolt
8
2
M8 Washer
9
18
M10 Washer
10
4
M6 Washer
11
2
M10 x 67mm Bolt
12
3
M10 x 48mm Bolt
13
1
Seat
14
2
M10 x 67mm Carriage Bolt
15
8
90mm Pulley
16
1
M10 x 80mm Bolt
17
1
Press Frame
18
2
M6 x 16mm Screw
19
2
Weight Bumper
20
1
Pulley Bracket
21
22
M10 Nylon Locknut
22
4
M10 x 75mm Bolt
23
1
Long Cable
24
1
M6 x 50mm Screw
25
6
Weight
26
1
Weight Pin
27
2
50mm Square Inner Cap
28
2
Pad Tube
29
1
Leg Lever
30
4
Small Pad
31
2
Handgrip
32
1
38mm Square Inner Cap
33
4
50mm Round Inner Cap
34
4
19mm Round Inner Cap
35
1
Eyebolt
36
1
Seat Frame
37
1
Seat Plate
38
1
M6 x 50mm Carriage Bolt
39
1
Handle
40
1
Seat Knob
41
1
Backrest
42
1
Front Upright
43
2
M6 x 65mm Screw
44
2
45mm Square Inner Cap
45
2
Large Pad
46
1
Right Press Arm
47
1
Left Arm
48
1
Right Arm
49
4
25mm Round Inner Cap
50
3
Long Cable Trap
51
2
Stabilizer Foot
52
1
Chain
53
3
Cable Clip
54
1
Lat Bar
55
1
Top Frame
56
4
M4 x 20mm Screw
57
1
Long “U”-bracket
58
1
Short Cable
59
1
M10 x 198mm Bolt
60
1
M10 x 155mm Bolt
61
2
13mm Spacer
62
2
Weight Guide
63
1
Weight Tube
64
1
Weight Tube Bumper
65
1
25mm Square Inner Cap
66
4
Cable Trap
67
1
Small “U”-bracket
68
1
M8 X 117mm Bolt
69
4
25mm Retainer
70
2
25mm Round Cover Cap
71
2
M10 x 95mm Bolt
72
1
M8 x 45mm Bolt
73
1
Left Press Arm
74
2
Butterfly Arm Bushing
75
2
25mm Plastic Bushing
76
1
Top Weight
77
1
38mm Round Inner Cap
78
2
25mm Round (thick) Inner Cap
79
2
50mm x 70mm Inner Cap
80
1
M8 x 57mm Bolt
81
2
M8 x 70mm Bolt
82
4
M4 Washer
83
1
M10 x 45mm Bolt
84
1
Support Plate
85
1
M10 x 90mm Bolt
86
1
M8 x 67mm Carriage Bolt
#
1
Grease Packet
#
1
User’s Manual
#
1
Exercise Guide
Key No. Qty.
Description
Key No. Qty.
Description
