11. Slide the burner assembly from each Heat Zone. The
left and right burners are connected by the Crossover
tube. Figure 14 (a).
Figure 14
Crossover tube
Pull out of here
9.
Unlatch the Spider Stopper Guards and remove.
Figure 12.
Figure 12
Manifold
10. Pull the manifold out of the burners. Figure 13.
Figure 13
MAINTENANCE
