Industrial Line 5000 Watt Power Inverter by Wagan Tech
USER’S MANUAL — Please read before using this equipment.
_______________________________________________________________________________________________________________________
TROUBLESHOOTING
© 2003 Wagan Corporation.
Condition
Solution
Poor contact
Clean contact parts thoroughly
Battery voltage is
too low
Start the engine to recharge the
battery. Replace the battery if
needed.
Shutdown on
overload
Reduce the wattage of inverter’s load
Thermal shutdown
Allow the inverter to cool down by
reducing the load or turn it off for a
while.
Receptacle has no
power
Check the receptacle wiring.
MAINTENANCE
Very little maintenance is required to keep the inverter
operating properly.
DESCRIPTION
10000W Peak Power — allow you to power appliances
that require a large amount of initial (peak) power to
work (such as many TVs and motor-power equipments).
Low Battery Alarm — the inverter sounds an audible
alarm then turns itself off if the source battery becomes
too low.
Auto Shutdown/Reset Protection — the inverter shuts
itself down to protect from low battery drained.
Overload/Short Circuit Protection — the inverter
automatically turns itself off if the connected load is too
high or if it shorts.
Fuse — the inverter comes with fuse/s already installed.
4 AC Outlets — allows you to power up many
appliances at the same time.
HEAT DISPERSAL
The inverter generates heat while it is working. This is
not a malfunction. However, if the inverter gets too hot
while working, it will turn off by itself.
Position the inverter where air flows freely around it to
allow the heat to disperse.
The inverter’s thermal protection prevents it from
operating when its temperature exceeds 130 ± 10
°F / 55
± 5
°C.
SPECIFICATION
Name
Description
Input
12V (10-15V) DC
Output 115V
AC
Output waveform
Modified Sine Waveform
Continuous power
5000 Watt
Surge power
10000 Watt
Efficiency
Approx. 90 %
No load current
< 0.3 A
Battery low alarm
10.5 ± 0.5 V DC
Battery low shutdown
10 ± 0.5 V DC
AC output socket
4 outlets of 3-prong
Power switch
DC input ON/OFF control
Dimensions 20x9x7
in³
Net Weight
22 lb
NOTE
All specifications are typical at nominal line, half load,
and 77
° F / 25° C unless otherwise noted. Specifications
are subject to change without notice.
