WIRE THERMOSTAT TO SYSTEM
For best electrical connection, use solid 18 gauge wire. If
you must use stranded wire, tin the wires with solder to
insure a good electrical connection.
1. Strip wires back
1
⁄
4
”.
2. Using needle-nose pliers, insert wire into correct termi-
nal block opening (see figs. 3 and 4).
3. Tighten terminal block connector screw.
4. Repeat steps 2 and 3 for each wire.
Some applications may require that the fan be disabled in
the Emergency Mode. Refer to System Function Table.
To prevent electrical shock and/or equipment
damage, disconnect electrical power to system,
at main fuse or circuit breaker, until installation is
complete.
This typical wiring diagram shows only the terminal iden-
tification and wiring hookup. Always refer to wiring instruc-
tions provided by equipment manufacturer for system
hookup.
All wiring should be installed in accordance with local and
national codes and ordinances.
NOTE
ATTACH SETPOINT KNOB AND COVER
1. After thermostat base is mounted on wall, remove
cardboard insert from setpoint switch.
2. Carefully press setpoint knob onto setpoint switch (see
fig. 5).
3. Carefully snap cover onto thermostat base. Refer to
the OPERATION section for instructions on setting the
thermostat for desired operation.
CAUTION
!
NOTE
