M10 Nylon Locknut (11)

M8 Nylon Locknut (13)

M6 Washer (30)

M8 Washer (23)

M6 x 16mm Screw (3)

Leg Lever Spacer (9)

16mm x 18.5mm Spacer (8)

M8 x 64mm Bolt (43)

M10 x 62mm Carriage Bolt (33)

M6 x 38mm Screw (4)

M6 x 62mm Screw (7)

M10 Washer (6)

M10 x 68mm Bolt (34)

M10 x 155mm Bolt (22)

M10 x 75mm Bolt (48)

Refer to the drawings below to identify small parts used in assembly. The number in parentheses by each draw-
ing is the key number of the part, from the PART LIST in the center of this manual.

Note: Some small parts

may have been pre-attached. If a part is not in the parts bag, check to see if it has been pre-attached.

PART IDENTIFICATION CHART
