Appendix A – PuigTec EQP-1A Controls
Control Range Default
Low Band Boost 0 to 11 (18 dB boost, 0.1 steps) 0
Low Band Atten 0 to 11 (18 dB boost, 0.1 steps) 0
Low Band Frequency 20Hz, 30Hz, 60Hz, 100Hz 30Hz
Hi Bell Boost 0 to 11 (18 dB boost, 0.1 steps) 0
Hi Bell Bandwidth (Q) 0 to 11 (0=sharp 11=wide,
0.1 steps)
0
Hi Bell Frequency 3kHz, 4kHz, 5kHz, 8kHz, 10kHz
12kHz, 16kHz
3kHz
High Shelf Atten 0 to 11 (18 dB boost, 0.1 steps) 0
High Shelf Frequency
(Atten Sel)
5kHz, 10kHz, 20kHz 20kHz
In In/Out In
Output -18dB to 18dB (0.1 steps) 0dB
Mains Off, 50Hz, 60Hz 60Hz
