CASTER PARTS
REF # PART # DESCRIPTION LS LT SS REF # PART # DESCRIPTION LS LT SS
1 98460013 L-S CASTER KIT W/O BRKT (SET OF 2) X 26 12990023 NUT, CASTLE 3/4-14 X
1A 98460005 L-T CASTER KIT W/O BRKT (SET OF 2) X 27 77460002 TAPERED BEARING FOR PIVOT X
2 93460006 CASTER ADJUSTMENT BRACKET X X 28 77460003 BEARING RACE FOR PIVOT X
3 98460016 L-S CASTER ARM (INCL 1-#20 & 2-#19) X 29 77460001 GREASE SEAL X
3A 93460005 L-T CASTER ARM WELDMENT X 30 13990021 BUSHING, MACHINE 7/8 ID X 1 3/8 OD X 1/4 X
4 93460008 L-S CASTER YOKE X 31 13990008 BUSHING, MACHINE 7/8 ID X 1 3/8 OD X 1/2 X
4A 93460004 L-T CASTER YOKE X 32 14990001 BUSHING, BRONZE(SAME AS VPIVOTBUSH) X
5 72460002 11X400-5 WHEEL ASSEMBLY COMPLETE X X 33 98460002 S-S CASTER ARM (INCL 2 #32 AND 1 #20) X
6 77460008 RIM ONLY X X 34 93460007 S-S CASTER YOKE X
7 77460009 TIRE ONLY X X 35 12990018 NUT, NYLOCK JAM 1/2-20 X
8 98460019 BEARING KIT (2 EACH #9, #10, #11, #12) X X 36 11990029 BOLT, HEX HD 1/2-20 X 5 Z5 X
9 77460004 WHEEL SPACER X X 37 13990019 BUSHING, MACHINE 3/4 X 1 1/4 X 14GA X
10 77460005 GREASE SEAL X X 38 13990018 BUSHING, MACHINE 3/4 X 1 1/4 X 10GA X
11 77460006 TAPERED ROLLER BEARING X X 39 72460003 9X350-4 PNEUMATIC WHEEL ASSEMBLY X
12 77460007 RACE, FOR BEARING X X 40 VKRLBRG ROLLER BEARING X
13 VKWHLZERK ZERK FITTING FOR WHEEL X X X 41 VKBRGRTNR ROLLER BEARING RETAINER X
14 11990034 BOLT, HEX HD 3/4-10 X 6 1/2 Z5 X X 42 VKSPNNR SPANNER X
15 12990026 NUT, NYLOCK JAM 3/4-10 X X 43 VKBRGKIT CASTER BEARING KIT (INCL #40, #41, #42) X
16 15990013 LYNCH PIN X X
17 13990023 MACHINE BUSHING 1 1/4 X 10 GA X
18 13990022 C- SPACER X
19 14990003 BRONZE BUSHING X
20 15990006 ZERK FITTING FOR CASTER ARM X X
21 98460018 CASTER BOLT KIT(8 BOLTS, 8 NUTS, 16 WASH.) X X
22 11990030 BOLT, FLANGE 3/8-16 X 3/4 Z5 X X X
23 12990008 NUT, FLANGELOCK 3/8-16 Z X X X
24 17460003 GREASE CAP X
25 15990012 PIN, COTTER 1/8 X 2 X
(c) 1998-2001 Wright Manufacturing, Inc. All rights reserved. rev. 12/01
