H-4
Because the sample UPC-E code ends in a 6, the insertion digits 0000 are inserted
at the sixth digit (insertion position 6):
1234500006
2. Add the Number System Character of 0 to the sample data:
01234500006
3. Use the UPC-A check digit calculation described in the previous section to
produce a check digit as if it were a UPC-A code. The check digit for the
sample data is:
5
4. The complete 8 digit code consists of the Number System Character, the
original 6 digit code and the check digit:
01234565
I f the code UPC-E data Insertion digits Insertion 10 digit code
ends in
:
Position
0 abcde0 0 0 0 0 0 3 ab 0 0 0 0 0 cde
1 abcde1 1 0 0 0 0 3 ab1 0 0 0 0 cde
2 abcde2 2 0 0 0 0 3 ab2 0 0 0 0 cde
3 abcde3 0 0 0 0 0 4 abc0 0 0 0 0 de
4 abcde4 0 0 0 0 0 5 abcd 0 0 0 0 0 e
5 abcde5 0 0 0 0 6 abcde 0 0 0 0 5
6 abcde6 0 0 0 0 6 abcde 0 0 0 0 6
7 abcde7 0 0 0 0 6 abcde 0 0 0 0 7
8 abcde8 0 0 0 0 6 abcde 0 0 0 0 8
9 abcde9 0 0 0 0 6 abcde 0 0 0 0 9
UPC-E Checksum Calculation
Use the sample data of 123456 to demonstrate the UPC-E checksum calculation:
1. The 6 digit UPC-E code is converted to a 10-digit code, using an expansion
scheme based on the sixth digit:
