Nozzles
Convertible nozzle
◗ With the brush strip folded in, the convertible nozzle can be used on carpets (fig. 6).
◗ With the brush strip folded out, the convertible nozzle can be used on hard floors (fig. 7).
Crevice tool, small nozzle and small brush
◗ These accessories can be found in the special storage compartment (fig. 8).
◗ Small nozzle (fig. 9).
◗ Crevice tool (fig. 10).
◗ Small brush (fig. 11).
Using the appliance
Adjusting suction power
1 You can adjust the suction power by means of the slide on the handgrip (fig. 12).
2 You can also adjust the suction power by turning the knob on the vacuum cleaner to the
desired setting (fig. 13).
- Set the knob to MAX for maximum suction power.
- Set the knob to MIN for minimal suction power.
Insufficient suction power
Please make sure that:
-
the knob on the vacuum cleaner is in the right position;
- the slide on the handgrip is closed;
- the dustbag is not full;
- the nozzle, tube or hose is not blocked up.
To remove the obstruction, disconnect the blocked-up item and connect it (as far as possible) in
reverse position. Switch the vacuum cleaner on to make the airflow suck the obstructing material
out of the blocked-up item.
Parking the tube
1 Insert the tube clip into the parking slot (fig. 14).
2 This allows you to park the tube in a convenient position in a single movement (fig. 15).
Storage
1 Switch the vacuum cleaner off.
2 Remove the mains plug from the wall socket.
3 Rewind the mains cord by pressing the cord winder button.
4 Put the appliance in upright position and attach the lower tube to the vacuum cleaner by
inserting the tube clip in the slot (fig. 16).
5 You can slide the clip along the tube to adjust its height (fig. 17).
