31 107156
OWNER’S MANUAL
For more information, visit www.desatech.com
PARTS LIST
FIREPLACE
VSGF28PTC
This list contains replaceable parts used in your fireplace. When ordering parts, follow the
instructions listed under Replacement Parts on page 22 of this manual.
KEY
NO.
PART NUMBER DESCRIPTION QTY.
1 101357-01 Top Outer Casing 1
2 103207-01 Outer Casing 1
3 102758-02CK Right Front Side 1
4 102759-02CK Left Front Side 1
5 098304-01 Phillips Pan Head Screw, #10 17
6 101351-01CK Top Front 1
7 102455-02 Louver Extruded 2
8 101353-01CK Middle Front Rail 1
9 101712-02 Firebox Hood 1
10 101348-01 Firebox Support 2
11 099230-01 Shoulder Screw 4
12 101872-03 Firebox Top 1
13 101346-01 Outer Base 1
14 101838-03CJ Firebox Wrapper 1
15 101614-02 Limit Switch (thermal disk) Assy. 1
16 M11084-26 Hex Screw, #10 57
17 098304-03 Phillips Pan Head Screw, #8 4
18 101727-03 Screen Assembly 1
19 101398-03 Wire Harness 1
20 103650-01 Control Knob 1
21 103581-02 Blower Assembly 1
22 099123-01 Wire Clip 4
23 105649-01 Blower Speed Control 1
24 M11084-38 Hex Screw, 8-18 x .38" 4
25 101629-01 Plastic Bushing 2
26 098544-01 Clamp 1
PARTS AVAILABLE — NOT SHOWN
099038-01 Strain Relief Bushing 1
100639-01 Caution Decal 1
103590-01 Decal Strip 1
104313-01 Hinge, Pin 1
104313-02 Hinge, Pin 1
M10908-2 Screw, Slotted Hex Head Tapping 4
