6
Microphone Connections
Connect up to two microphones to the DVX-880 PRO, by connecting a 1/4” cable to the MIC 1 and 2 inputs
on the DVX-880 PRO.
NOTE: Microphone vocals are only output from the MIC and MUSIC OUT on the rear panel of the DVX-880 PRO.
You will not hear the vocals if you are not outputting from these outputs.
Getting Connected
PLAY/PAUSE STOP PREV NEXT
REPEAT OPEN/CLOSE
DIGITAL KEY
CONTROL
DIGITAL
ECHO
D V X - 8 8 0 P R O M U L T I F O R M A T K A R A O K E P L A Y E R
CDG
J P E G
P H O T O C D
Setting the correct video mode
Depending on which video connection you are using, you may need to change the DVX-880 PRO’s video output
settings by pressing the V-MODE button on the remote control.
The V-MODE button toggles between the following modes:
P-Scan: Standard video mode.
SCART: When using the SCART output
S-Video: When using the S-Video output
YUV: When using the Component outputs
MIC CONNECTION
