5
1
STEP
1
STEP
• Slide the rubber covers on to the left
& right console supports, making sure
that the lower cutout is facing inward.
• Insert one of the console supports
into the console support bracket and
secure with two bolts (M8 x 20L) in
the side of the console support
bracket.
• Insert one bolt (M8 x 20L) in the
rear of the console support bracket.
• Tighten all three bolts with the blue-
handled 5
MM Allen wrench.
• Repeat this on the opposite side.
NOTE: The right console support has
a white wire tie attached to it.
ORANGE BAG
