5
Vax Careline 0870 606 1248
emptying the recovery tank / transporting
Emptying the Recovery Tank
IMPORTANT: Unplug carpet cleaner from electrical outlet.
An automatic shut-off device prevents the carpet cleaner
from picking up more dirty water than it can hold in the
recovery tank.
You will know the tank needs to be emptied -
• When the motor sound rises in pitch.
• You do not see dirty solution coming up through the
recovery tank lid.
• The float (A) inside the recovery tank has risen to the top
of the tank (Fig. 3/8), and is visible through the lid
window (B).
Step on handle release pedal (C) to lower handle and
unlock the recovery tank (Fig.3/9).
Lift up on tank (D) and pull off (Fig.3/10).
Lift up on tank lid latches (E) and remove the tank lid (F),
including the float (G) (Fig.3/11). Empty tank.
Replace lid. Secure both latches (E) (Fig.3/11).
NOTE: For full suction, it is important that the recovery
tank lid is properly secured before replacing or operating.
Remove any debris that has collected on lint filter (H) on
cleaner body (Fig.3/12 and inset).
Place tank onto cleaner. Return handle to upright position.
Transporting
Your carpet cleaner may be transported easily by the
convenient carrying handle (see item 4, page 2).
Fig.3/7
Fig.3/8
Fig.3/9
Fig.3/11
Fig.3/12
Fig.3/10
A
C
B
D
E
F
E
G
H
