08 Maintenance and specifications
Fuses
08
``
*
Option/accessory, for more information, see Introduction.
321
Engine compartment, upper
Engine compartment, front
Engine compartment, lower
Positions
These fuses are all located in the engine com-
partment box. Fuses in
are located under
.
NOTE
•
Fuses 16 – 33 and 35 – 41 may be
changed at any time when necessary.
•
Fuses 1 – 15, 34 and 42 – 44 are relays/
circuit breakers and should only be
removed or replaced by a trained and
qualified Volvo service technician.
•
There is a special fuse removal tool on
the underside of the cover.
Pos
Function
A
Circuit breaker
50
Circuit breaker
50
Circuit breaker
60
Circuit breaker
60
Pos
Function
A
Circuit breaker
60
–
–
Headlight washers*
20
Windshield wipers
30
–
Climate system blower
40
–
ABS pump
40
ABS valves
20
–
Active Bending Lights-
headlight leveling*
10
Central electrical module
20
ABS
5
Speed-dependent steering
force*
5
Pos
Function
A
Engine Control Module
(ECM), transmission, SRS
10
Heated washer nozzles*
10
Vacuum pump (5-cylinder
engine)
5
Lighting panel
5
-
-
-
Relay - engine compart-
ment box
5
Auxiliary lights*
20
Horn
15
Engine Control Module
(ECM)
10
Control module - automatic
transmission
15
A/C compressor
15
Relay-coils
5
