Vision Fitness R2750HRT - Manual

5mm T-Shaped W rench
Screwdriver
5mm L-Shaped Wrench
TOOLS & PA RTS INCLUDED
4mm L-Shaped Wrench
ORANGE BAG GREEN BAG
PINK BAG
HARDWARE INCLUDED
PA RTS BOX
Console Mast Cover
Water Bottle
Heart Rate Chest Strap
Color-coded Hardware Bags
Pedals/Straps
Ow ner ’s G uid e
Assembly Guide
Warranty Card
BLUE BAG
M8 x 15L Bolt
Quantity: 6
M8 x 20L Bolt
Quantity: 2
M8x65L Bolt
Quantity: 2
M8 Lock Washer
Quantity: 4
M8 x 15L Bolt
Quantity: 2
M8 Lock Washer
Quantity: 2
BLACK BAG
M6 x 55L Bolt
Quantity: 4
M6 Lock Washer
Quantity: 4
M8 x 20L Bolt
Quantity: 8
M8 Lock Washer
Quantity: 8
15mmP edal Wrench
YELLOW BAG
M5 x 35L Bolt
Quantity: 2
M5 Lock Washer
Quantity: 2
M10 x 12L Set Screw
Quantity: 1
500 South CP Avenue • P.O. Box 280 • Lake Mills. WI 53551
toll free 800.335.4348 • phone 920.648.4090 • fax 920.648.3373
www.visionfitness.com
©2006 Vision Fitness. All Rights Reserved. 11.06
AG18.46PRD
REV1
