OWNER’S MANUAL
For more information, visit www.desatech.com
KEY
NO.
PART NUMBER
DESCRIPTION
QTY.
1
106796-01BR
Firebox Assembly
1
2
105795-01
Glass Door Assy
1
3
106836-02CK
Rear Cover
1
4
M11084-46
Screw, Hex
11
5
107013-01
Center Cast Grate
1
6
099998-01
On/Off Switch
1
7
103284-07
Wire Harness
1
8
103284-06
Wire Harness
1
9
107191-01
Baffle
1
10
105494-01
Spillswitch
1
11
M11084-43
Switch Screw
2
12
105468-01
Valve Bracket
1
13
105489-01
Valve, Natural
1
105489-02
Valve, Propane/LP
1
14
105488-01
Pilot Assembly, Natural
1
105488-02
Pilot Assembly, Propane/LP
1
15
102445-01
Ignitor, Piezo
1
16
107195-01
Bracket, Spill Switch
1
17
106036-01
Burner, Natural
1
106036-02
Burner, Propane/LP
1
18
104506-16
Orifice, Natural
1
104506-17
Orifice, Propane/LP
1
19
104507-01
Brass Elbow
1
20
901063-01
Brass Elbow
2
21
101628-04
Flex Tubing
1
22
105325-01
Air Deflector
1
23
105491-01
Log Set
1
23-1
105774-01
Rear Log
1
23-2
105774-02
Front Log
1
23-3
105774-03
Crossover Log
1
23-4
105774-04
Log Piece
1
24
098304-03
Screw
2
25
M12461-50
Screw
3
26
M12461-65
Screw
2
27
106794-01
Grate Assembly
1
GA6060
Lava Rock
1
104529-01
Ember Material
1
M11084-26
Hex Screw for Blower Bracket
4
PARTS AVAILABLE - NOT SHOWN
PARTS LIST
SBVBN(C)
SBVBP(C)
This list contains replaceable parts used in your burner system. When ordering parts, follow the
instructions listed under Replacement Parts on page 26 of this manual.
