PARTS LIST This list contains replaceable parts used in your fireplace. When ordering parts,
follow the instructions listed under Replacement Parts on page 28 of this manual.
KEY VMH26TN
NO. PART NO. DESCRIPTION QTY.
1 102633-01 Outer Casing Top 1
2 102624-02 Outer Casing 1
3 099230-02 Shoulder Screw 4
4 098304-01 Screw, #10 x 3/8" 40
5 099126-02 Burner 1
6 103209-02 Louvered Door 1
7 102635-01CK Left and Right Side Front 2
8 102458-01CK Top and Middle Front 2
9 103209-01 Brass Top Louver 1
10 102730-01CJ Firebox Hood 1
11 102638-01 Firebox Top 1
12 103042-01 ODS/Pilot Assembly 1
12-1 098514-01 Thermocouple 1
12-2 098594-01 Ignitor Electrode 1
13 102460-01CJ Firebox Wrapper 1
14 099211-01 Control Bracket Screw 2
15 103963-01 Inlet Tube 1
16 102834-01 Burner Tube 1
17 100587-01 Brass Screw, #6 x 3/8 4
18 098303-02 Regulator Screw 2
19 102634-01CK Outer Shell Base 1
20 102649-01CJ Twig Support 1
21 099415-10 Gas Regulator 1
22 102875-01 Regulator Bracket 1
23 101381-01 Valve Cover and Piezo 1
24 099387-03 Pilot Tube 1
25 098271-06 Ignitor Cable 1
26 098251-04 Injector 1
27 098250-01 Injector Holder 1
28 098249-01 Nut, M5 6
29 098522-14 Gas Valve 1
30 102639-01 Baffle 1
31 101628-01 Flexible Connector 1
32 102869-01 Control Bracket 1
33 102731-01 Control Shield 1
34 103295-01CJ Screen Assembly 1
35 103058-01 Log Set Assembly 1
35-1 104058-01 Twig Service Kit 1
35-2 104058-02 Back Log Service Kit 1
36 102032-01 Hinge 2
37 102807-01 Hinge Screws 8
38 102645-02 Burner Support, Right 1
39 102645-01 Burner Support, Left 1
40 097809-03 3/8" NPT x 3/8" Flare Brass Fitting 1
41 101416-32 Video 1
PARTS AVAILABLE — NOT SHOWN
101054-01 Lighting Instructions Plate 1
100563-01 Warning Plate 1
103470-01 Hardware Package 1
Model: VMH26TN
