V-008T
1. Diagram
www.vax.co.uk
2 parts overview
1
2
3
4
5
6
21
13
14
15
16
17
18
19
20
21
11
7
8
9
10
12
Fig.1/1
1 Handle grip
2 TurboTool
3 Hose
4 Dirt container release button
5 Crevice tool - inside extension tube
6 Extension tube
7 Dirt container
8 Air Directors
9 Centre dirt path
10 Clean release empty button
11 Carpet height adjuster
12 Scuff guard bumper
13 Cord grip
14 Hose guide
15 Cord wrap with quick release
16 Long power cord
17 Carry handle
18 Dust brush
19 Handle release pedal
20 On/Off pedal
21 Wheels
