cport control Channel port
vport video Channel port
aport audio Channel port
yes optimal for the low bandwidth band
no keep the original way
ssid characters> WLAN SSID
inf WLAN infrastructure mode wl
ad WLAN Ad Hoc mode
1 ~ 11 channel in USA
1 ~ 11 channel in Canada
1 ~ 13 channel in Europe
10, 11 channel in Spain
10 ~ 13 channel in France
chan
1 ~ 14 channel in Japan (all)
1 1 Mbps transmission rate
2 2 Mbps transmission rate
3 5.5 Mbps transmission rate
4 11 Mbps transmission rate
tx
5 22 Mbps transmission rate
l long preamble preamb
s short preamble
yes enable data encryption encr
no disable data encryption
auto auto authentication
shared shared-key authentication
auth
open open-key authentication
1 64 bits key length
2 128 bits key length
klen
3 256 bits key length
h hexadecimal format of key kform
a ASCII format of key
dkey 1 ~ 4 one of four keys
netkey1 hexadecimal string (00 ~ FF) network key 1
