14
7.3 V191 series product specifications
V191 Series
Panel Type:
Size:
Pixel Pitch:
Brightness:
Contrast Ratio:
Response Time:
Viewing Angle(H / V)
Max. Resolution:
Display Color
Active TFT-LCD
19”
diagonal
0.294 (W) ×0.294 (H) mm
Typical: 250 cd/㎡ (Min: 250)
Typical: 800:1 (Min: 500:1)
Typical: 8 ms (Max: 16)
Typical: 170°/170° (Min: 140° / 140°)
1280 (W) x 1024 (H)
16.7M
Video Input Analog:15-pin, D-sub connector
S-video x1, RCA composite x1
Display Area 14.8 (W) x 11.8 (H) inch
[376 (W) x 301 (H) mm]
Power Supply
Input voltage:
Output rating:
100-240V /60-50Hz
12V DC, 4.2A
Power Consumption 50 watts (maximum), 3 watts (standby)
Audio 3 watts x 2 built-in speakers
RCA composite x1
Frequency Horizontal:30-82KHz; Vertical: 50-75Hz
Dimensions(set size) 16.7 (W) x 16.7 (H) x 6.9 (D) inch
[ 425 (W) x 425 (H) x 175 (D) mm]
Safety & EMI UL, CUL, FCC-B, CB, CE, TUV/GS
Weight N.W.: 13.2 lbs (6.0Kgs)
G.W.: 16.5 lbs (7.5Kgs)
Operating Conditions 5°C – 35°C; 20%-80% RH
Storage Conditions: -20°C – 60°C; 10%-90% RH
Wall mountable Yes, VESA 75 bracket
The optical specifications (brightness, contrast ratio, response time and viewing angle) depend on
the LCD panel used, subject to change without notice. For the latest update, please refer to
ViewEra’ s product page on the website.
Model
Features
