Page 3
3
1a,b,c
3a,b,c
2a,b,c
4a,b,c
5a,b,c
6
7
8
13
12
9
10
11
15
17
19
20
18
24
16
22
23
14
21
8881
Marquette parts
3/06
CFM Corporation reserves the right to make changes in design, materials, specifications, prices and discontinue colors and products at any time,
without notice.
Ref.
Description
Marquette
1a.
Panel Top w/Hood Assembly Black
10009087
1b.
Panel Top w/Hood Assembly Rustic Bronze
10009027
1c.
Panel Top wi/Hood Assembly Pewter
10008798
2a.
Frame Upright Left Assembly Black
10009092
2b.
Frame Upright Left Assembly Rustic Bronze
10008974
2c.
Frame Upright Left Assembly Pewter
10008974
3a.
Frame Upright Right Assembly Black
10009091
3b.
Frame Upright Right Assembly Rustic Bronze
10009031
3c.
Frame Upright Right Assembly Pewter
10008972
4a.
Plate Pattern Black
10009088
4b.
Plate Pattern Rustic Bronze
10009028
4c.
Plate Pattern Pewter
10008819
5a.
Access Panel w/Stud Assembly Black
10009090
5b.
Access Panel w/Stud Assembly Rustic Bronze
10009030
5c.
Access Panel w/Stud Assembly Pewter
10008796
Marquette Trim Kit Replacement Parts
