VIEWSONIC LCD Display VS11280 - Manual (Page 12)

ViewSonic VA703m/VA703b/VA703mb 9
Adjusting the Screen Image
Use the buttons on the front control panel to display and adjust the OSD controls which display
on the screen. The OSD controls are explained at the top of the next page and are defined in
“Main Menu Controls” on page 11.
Main Menu
with OSD controls
Front Control Panel
shown below in detail
Scrolls through
menu options and
adjusts the
displayed control.
Also a shortcut to
display the
Contrast
adjustment control
screen.
Displays the control screen
for the highlighted control.
Also toggles between two
controls on some screens.
Also a shortcut to Auto
Image Adjust.
Power light
Green = ON
Orange = Power Saving
Standby Power
On/Off
Displays the
Main Menu or
exits the
control screen
and saves
adjustments.
VA703m/VA703mb VA703b
