CABINET CONSTRUCTION
The cabinet front, doors, sides, top and interior are constructed of heavy gauge,
polished stainless steel to maintain an attractive appearance after years of heavy use.
Foamed-in place polyurethane insulation throughout the cabinet and drawers ensures
the ultimate in energy efficiency. The front grille is removeable to provide easy access to
the condenser and facilitate cleaning.
DRAWER CONSTRUCTION
The drawers are heavy gauge, polished stainless steel with 14 gauge stainless steel
slides. Each drawer is self-closing with a stay open feature. The horizontal handles
are guaranteed for life. Each drawer has a snap-in place magnetic gasket for a positive
seal. Perimeter heater wires around the drawer openings help prevent condensation
from forming on the front of the cabinet. Each heater wire is concealed and protected
by a high impact, non-conducting breaker cap.
REFRIGERATION SYSTEM
A high efficiency, air-cooled, self-contained refrigeration system is mounted on the side
of the cabinet and located behind the easily removable front louvered grille. Envi-
ronmentally friendly R-134a refrigerant is efficiently metered by a capillary system
providing a constant, safe operating temperature and quick “recovery” under the most
demanding conditions. The hermetically sealed system is designed to operate at 38°F.
The fans and cooling coil, which is plasticized to resist food acids, move cold air from
side to side, top to bottom to keep food product at a safe storage temperature. All
condensate water is disposed of automatically by the energy efficient, electric
condensate evaporator.
INTERIOR STORAGE ARRANGEMENTS
Each drawer accomodates two (2) 12” x 20” x 4” pans (not included).
GRIDDLE STAND REFRIGERATORS
Copyright March 2013
Printed in USA
We reserve the right to change specifications and product design without notice. Such revisions do not entitle the
buyer to corresponding changes, improvements, additions or replacements for previously purchased equipment.
Dimensional tolerances +/-
1
⁄
4
”. Metric dimensions (MM)
CHARACTERISTICS
1 SECTION
2 SECTION
3 SECTION
DIMENSIONAL DATA
Capacity Net (cubic ft.)
Width*, Overall (in.)
* Remote Width, Overall (in.)
Depth, Overall (inc. handles)
Height Overall (inc. 6” legs)
No. of Drawers
No. 12” x 20” Pans (not included)
ELECTRICAL DATA
Cabinet Voltage
Feed Wires
Condensing Unit Voltage
NEMA Plug
Total Amperes
MAXIMUM LOAD
On Top of Griddle Stands (lbs)
REFRIGERATION DATA
Condensing Unit Size
Refrigerant
6.0
50
1
⁄
8
NA
34
5
⁄
8
25
1
⁄
2
2
4
115/60/1
2
115/60/1
5-15 P
8
450
1
⁄
4
HP
R-134a
1
⁄
4
HP
R-134a
1
⁄
4
HP
R-134a
34
1
⁄
4
34
1
⁄
4
34
1
⁄
4
56
1
⁄
4
83
1
⁄
4
111
38
3
⁄
4
38
3
⁄
4
38
3
⁄
4
43.20
63.94
85.25
330
410
560
115/60/1
2
115/60/1
5-15P
8.3
800
115/60/1
2
115/60/1
5-15P
8.6
1300
12.0
77
1
⁄
4
60
1
⁄
2
34
5
⁄
8
25
1
⁄
2
4
8
18.0
105
87
5
⁄
8
34
5
⁄
8
25
1
⁄
2
6
12
NOTE: Plug style, voltage and full load amps may vary depending on certain
options selected such as special voltages and compressor upgrades.
REMOTE APPLICATIONS: See form V-RRDS1 for remote refrigeration
characteristics by model.
NOTE: In order to provide peak operating performance the cabinet must
have a 2 inch all around clearance.
CRATED DIMENSIONS & WTS.
ONE SECTION
TWO SECTION
THREE SECTION
HT.
WIDTH DEPTH
FT³
LBS
