Attachments
M I N U T E M O U N T / 3 - N - 1
All Ventrac attachments mount in about a minute or less.
Ventrac’s
Minute Mount System
is the ultimate
example of practical engineering put to good use.
Simply drive up to the Ventrac attachment of
choice:
1.
Lock onto the holding pins
2.
Insert the coupler connections* and/or...
3.
Install the drive belt*
4.
Engage the belt tensioner*
And you’re ready to go!
*As required by attachment
Rear Attachments
Ventrac 4000 series tractors can be equipped with a Category One 3-point hitch. With the
3-N-1 adapter mounted to the optional Category One 3-point hitch, non-powered attachments
can be operated from behind the tractor alone or simultaneously with the front.
Versatility by
Design
just got better!
AERATOR
EB480
The Ventrac Aerator offers the exact tools to address your
turf grass conditions. Choose between core or open spoon
tines. The tines are replaced either individually or by quickly
changing the entire
mounting heads.
Overall
width
54”
Overall height
27”
Overall length
27”
Working width
48”
Aeration density
6 holes/f
2
Weight
217 lbs.
AERA-VATOR
EA600
The AERA-vator is designed to fracture the soil beneath
the sod without destroying the turf on the surface. This
means that turf is ready for use immediately after treatment.
Penetrating the soil with no slicing or cutting action,
preserves the delicate turf grass roots and stimulates
future growth.
Optional: Seed-box (shown) allows
for over-seeding and
aerating simultaneously.
Overall width
66”
Overall height
22”
Overall length
34”
Working width
60”
Tines
96 (0.5625 x 3.5”)
Weight
350 lbs.
Side-to-side tine travel
1.25”
Vibrating depth
3.75”
Tine vibration frequency
3200 rpm
=est. 800 cyc/min
Aeration density
8 holes/f
2
4000 7000
series
Attachments with this symbol can also be
mounted to the rear using Ventrac’s optional
3-point hitch and 3-n-1 adapter.
1
2
3
4
BLADES
The Dozer Blade is hydraulically angled left and right.
Adjustable skid shoes, removable locking pin, and
reversible cutting edge are standard.
Optional: Polyurethane cutting edge and hard-
ened cutting edge.
KD480
KD600
KD720
Width
48”
60”
72”
Height
22”
22”
22”
Angle (right or left)
30º
30º
30º
Weight
163 lbs.
203 lbs.
225 lbs.
3000 4000 7000
series
BLOWER
KA160
The KA160 Power Blower for the 4000 and 7000 series
tractors rotates 180º horizontally left and right with a
standard hydraulic motor controlled
from the operator seat.
Overall width
32.5”
Overall height
22”
Overall length
36”
Fan
16 blade
Wind speed
180 mph
Volume
4000 cfm
Weight
163 lbs.
Hydraulic motor
Standard
4000 7000
series
BLOWER
LA162
The LA162 Blower for the 3000
series tractor can be angled 180º
horizontally left and right with the
standard hydraulic motor.
Overall width
32.5”
Overall height
22”
Overall length
42”
Fan
16 blade
Wind speed
160 mph
Volume
3400 cfm
Weight
145 lbs.
Hydraulic motor
Standard
3000
series
BROOM
HB580
The HB580 Broom for the 4000 and 7000 series
tractors is hydraulically driven and can be
angled right or left using the
auxiliary S.D.L.A. lever.
Optional: 12V Actuator allows
the operator to slow or reverse
the rotation of the
bristles from the
operator seat.
Overall width
68”
Overall height
24”
Overall length
54.5”
Broom width
58”
Broom speed
220 rpm*
Weight
382 lbs.
Gauge Wheels
Standard
*Engine speed 3200 rpm
BROOM
LB540
The LB540 Broom for the 3000 series tractor is hydrau-
lically angled left or right using the Auxiliary lever.
Optional: Belting curtain and outrigger wheels (inset)
for de-thatching your yard.
Broom width
54”
Overall width
60.5”
Overall height
18.5”
Overall length
46.5”
Broom diameter
16”
Broom speed
300 rpm*
Weight
240 lbs.
Gauge wheels
Standard
*Engine speed 3200 rpm
EDGER
ED200
The Edger is designed to edge sidewalks, curbs, cart
paths, etc. The edging disc can be reversed for shaping
garden and flower beds.
Optional: Weights and blower* for removing
edged debris.
Overall width
54-66”
Overall height
27”
Overall length
45”
Weight
182 lbs.
Weight w/blower
222 lbs.
Disc diameter
20”
Cutting depth
6”
3000 4000 7000
series
*Blower attaches only to 4000 and 7000 series
EXCAVATORS
HJ Excavator buckets allow the
operator to excavate, dig, and
haul material. Its innovative flip-
back design allows for forward
or reverse excavating.
HJ300
HJ480
Overall width
36”
53.5”
Working width
30”
48”
Height
13”
13”
Length
34”
34”
Capacity
3.6 ft
3
5 ft
3
Ground clearance
11”
11”
Weight
145 lbs.
189 lbs.
3000 4000 7000
series
FIELD MOWER
LQ450
The LQ450 Field Mower is designed to cut heavy grass
and small brush growth with three different height
settings. Two counter-rotating blades discharge grass
to the center rear.
Optional: Tree Shield Kit with
branch lifters and wheel cov-
ers for tree farms (rear weights
recommended).
Cutting width
44.5”
Cutting height
2.25” / 3.5” / 4.75”
Height
16”
Length
55”
Weight
243 lbs.
3000
series
GENERATOR
HG150
The Ventrac Generator is
great for mobile power or
as a standby unit.
Receptacles include: (4)
120v, 20A receptacles;
(1) 120v, 30A Twistlock,
(1) 240v, 30A Twistlock,
(1) 240v, 50A Range re-
ceptacle.
Maximum watts
15,000
Continuous watts
12,500
Voltage
120/240
Amperage
79.2/39.6
Hertz
60
Phase
1
Req. constant shaft speed
3,000 rpm
Net weight
196 lbs.
4000 7000
series
4000 7000
series
3000
series
3000 4000 7000
series
