User's Manual - 87
65535
Subgroup of network: rtsp
NAME VALUE DEFAULT SECURITY
(get/set)
DESCRIPTION
port 554, 1025 ~
65535
554 1/6 RTSP port
authmode disable,
basic,
digest
disable 1/6 RTSP authentication mode
s0_accessname string[32] live.sdp 1/6 RTSP access name for
stream1
s1_accessname string[32] live2.sdp 1/6 RTSP access name for
stream2
s0_audiotrack 0 6/6 The current audio track for
stream1.
-1 => audio mute
s1_audiotrack 0 6/6 The current audio track for
stream2.
-1 => audio mute
Subgroup of rtsp_s<0~(n-1)>: multicast, n is stream count
NAME VALUE DEFAULT SECURITY
(get/set)
DESCRIPTION
alwaysmulticast 0 4/4 Enable always multicast
ipaddress For n=0,
239.128.1.
99
For n=1,
239.128.1.
100,
and so on.
4/4 Multicast IP address
videoport 1025 ~
65535
5560+n*2 4/4 Multicast video port
audioport 1025 ~
65535
5562+n*2 4/4 Multicast audio port
ttl 1 ~ 255 15 4/4 Multicast time to live value
