2-2 Hardware Description
Enclosure
Enclosure
Introduction This section describes the components of the Vanguard 342 enclosure.
Vanguard 342
Enclosure The Vanguard 342 fits into a compact, low profile enclosure case that can be:
• used as a desktop standalone device
• seated on a shelf in a standard 19-inch equipment rack
• bracketed to the underside of a desktop or vertical surface
The enclosure contains a motherboard and (two optional) daughtercards.
Front Panel The front panel of the Vanguard 342 (see Figure 2-1) includes:
• 10 LEDs that provide node status
• Reset button
For a full description of all Front panel LEDs and reset button, refer to the
“Powering Up Your Vanguard 342” section in Chapter 4.
Figure 2-1. Vanguard 342 Front Panels
Reset
LEDs
