OWNER’S MANUAL
PARTS LIST
VP2000BTD
VP2800BTD
This list contains replaceable parts used in your heater. When ordering parts, follow the instructions listed
under Replacement Parts on page 17 of this manual.
KEY
PART NUMBER FOR
NO.
VP2000BTD
VP2800BTD
DESCRIPTION
QTY.
1
098304-01
098304-01
Screw, #10 x 3/8"
2
2
098742-13
098742-14
Front Panel
1
3
103476-01
103476-02
Grill Guard
1
4
101108-01
101108-01
Clip, Grill Guard
2
5
104189-01
104189-02
Bottom Glass Retainer
1
6
098260-09
098260-10
Glass Panel
1
7
NJF-8C
NJF-8C
Hex Nut
1
8
M11084-26
M11084-26
Screw, #10 x 3/8"
6
9
104618-01BR
104618-02BR
Deflector Unit
1
10
098271-03
098271-03
Ignitor Cable
1
11
098249-01
098249-01
Nut, M5
2
12
103594-04
103594-04
ODS/Pilot Assembly
1
12-1
098514-01
098514-01
Thermocouple
1
12-2
106842-01
106842-01
Ignitor Electrode
1
13
103446-01
103447-01
Burner
1
14
099387-03
099387-03
3/16" Pilot Tubing
1
15
103845-05
103845-07
Injector
1
16
099066-01
099066-01
Mounting Bracket
1
17
099415-06
099415-06
Pressure Regulator
1
18
099553-01
099553-01
Pilot Shield
1
19
103255-01
103255-01
3/8" Outlet (Burner) Tubing
1
20
103256-01
103256-01
3/8" Inlet Tubing
1
21
098522-11
098522-13
Thermostat Gas Valve
1
22
104617-03
104617-04
Cabinet
1
23
097159-04
097159-04
Piezo Ignitor
1
24
M11084-38
M11084-38
Screw, #8 x 3/8"
2
PARTS AVAILABLE — NOT SHOWN
098305-01
098305-01
Control Position Label
1
100642-01
100642-01
Hardware Assembly
1
