Vizio E 131 - Manual (Page 2)

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
General Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Appearance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Performance Graphs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Input/Output Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Installation Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9~10
1. XLR type audio connectors are wired in accordance with NAB standards.
Pin 1 is ground (shield), pin 2 is cold (low, minus), and pin 3 is hot (high,
plus).
2. The E 131 has two versions, 120V AC operation only and 220/240V AC
operation with a voltage selector. The voltage selector on the rear panel of
the 220/240V version should be checked for proper setting prior to operation
as improper setting causes trouble. The voltage selector is set for 240V
operation at the factory.
3. Do not operate the E 131 from power mains which exceeds the indicated
mains voltage by more than 10%.
4. Do not expose the E 131 to corrosive chemicals or liquids such as soft drinks,
salt water, etc.
5. Always refer the E 131 to qualified technical service personnel. There are
no user serviceable parts inside.
- 1 -
Contents
Precautions
