1. IInnppuutt//OOuuttppuutt SSiiggnnaall - Connect these
RCA jacks as described in the Front
Panel Connections/Controls section
of this guide.
2. RReem moottee SSuubb LLeevveell CCoonnttrrooll - Connect
the Remote Sub Level control to the
1100.5 only. The 1100.5 control
panel subwoofer adjustments are
used first to set the overall gain for
all synced amplifiers, then the
Remote Sub Level control can adjust
the gain of all synced amplifiers by
adjusting its control knob.
3. SSiiggnnaall CCoonnnneeccttiioonn - Connect an RCA
cable between the SYNC OUT RCA
jack of the 1100.5 and the SLAVE
IN RCA jack of the slaved d600.1 as
shown in Figure 5.
4. SSllaavvee//M Maasstteerr SSw wiittcchh - Set the
slave/master switch of the d600.1
to the slave position. This will put
the I/O RCA jack in the SLAVE IN
mode so it will accept the audio
signal from the 1100.5’s sync out
RCA jack.
5. SSuubbw wooooffeerr SSppeeaakkeerr CCoonnnneeccttiioonn - In
this amplifier combination each
amplifier must drive its own separate
subwoofer(s). Connect the speaker
terminals of each amplifier to any
combination of one or more
subwoofers that results in nominal
impedance between 1 and 4 ohms.
Make sure that each amplifier sees
the same speaker impedance.
PARALLEL SYNCED GAIN CONNECTIONS/SETTINGS
