Varimixer W60P - Manual

Specifications
Standard Features
W60P
Models
W60P Food Mixer
W60P F
ood M
ix
er
Project
Item
Quantity
CSI Section 11400
Approval
Date
Options &
Accessories
• Powerful 4 hp motor
• Variable speeds from 60 to 300 RPM
• By manually operating a single lever, the
bowl raises and locks in position.
• Overload protection and no voltage
release
• No bowl adaptors required for the down-
size bowls
•#12 attachment hub with 198 rpm speed
• Locking pin on tools instead of shaft.
• Neoprene feet to minimize walking and
rusting
• Permanently lubricated planetary head
and attachment hub case
• 15-minute timer with HOLD feature
• Stainless steel 60-qt. bowl and dough
hook
30-qt. bowl and accessories
Bowl scraper in 60-qt. and
30-qt. sizes
Stainless steel wing whip
Pastry knife
Bowl Truck with handle
Vegetable slicer and shredder
plates
Meat grinder
Power Bowl Lift
Mark IV programmable
controls
Ergo (tall column)
Wire Whip
Alloy Flat Beater
5489 Campus Drive
Shreveport, LA 71129 USA
Tel: 318-219-7051
Tel: 1-800-222-1138
Fax: 318-635-3131
E-mail: [email protected]
www.varimixer.com
Bulletin No. W60P 09/07
Mixing system
The VARIMIXER W60P is a planetary mixer with
a variable speed drive system. The mixer frame
consists of a column with welded-on feet, and
a top traverse closed by a stainless steel cover.
The bowl is mounted in bowl arms which are
manually raised and locked simultaneously - or
lowered and opened, respectively. The column
contains the motor and the bowl arm mecha-
nism. The top traverse contains the transmis-
sion system consisting of the moveable pulleys,
the intermediate belt drive and the planetary
head. Start and stop push buttons are mounted
on the frontplate along with a 15-minute
electrical timer with a HOLD feature. Mixing
tools are mounted in a bayonet shaft in the
planetary head.
Construction
Mixer frame of heavy-gauge, welded, rolled
steel plate. Durable powder coated finish
used on those surfaces not constructed of
stainless steel. Top cover, splash apron and
planetary head cap in heavy-gauge stainless
steel. Molded PVC feet pads. Bowls in stainless
steel. Mixing tools in cast aluminum or stainless
steel. Bayonet shaft in stainless steel. Variable speed V-belt transmission based on precision
machined cast iron pulleys. Springloaded
moveable pulleys in the variable speed drive
for automatically adjusting of the tension of
the special V-belt. Planetary mixer head of
unique design. The planetary head revolves in
heavy-duty ball and needle bearings around
the main shaft. Precision milled beveled gear
on the main shaft engages the bayonet shaft
and the fixed internal gear ring through a
double set of milled gears obtaining extra high
torque capabilities of the mixing tools.
Precision milled cast iron bowl arms lower and
raise the bowl and clamp it in a precise position
relative to the mixing tool allowing for small
tolerances between tool extremities and the
bowl.
Attachment drive directly coupled to the motor
securing maximum power output to the meat
grinder or vegetable cutter. The 198 rpm high
speed and the powerful motor give the meat
grinder an unusually high capacity in relation
to the size of the mixer.
