lowluxmode
(r/w)
0 or 1
Turn off or on low lux mode
obwlowluxmode
(r/w)
0 or 1
Turn off or on black/white video in low
lux mode
enableblc
(r/w)
0
or
1
Disable or enable back light
compensation.
blcsenslevel
(r/w)
0~7
Set back light compensation level
blcarea(0)
(r/w)
0~255
First row in BLC area. 0 to indicate
disabling all sub windows. 255 to
indicate enabling all sub windows.
blcarea(1)
(r/w)
0~255
Second row in BLC area.
blcarea(2)
(r/w)
0~255
Third row in BLC area.
blcarea(3)
(r/w)
0~255
Fourth row in BLC area.
blcarea(4)
(r/w)
0~255
Fifth row in BLC area.
blcarea(5)
(r/w)
0~255
Sixth row in BLC area.
Drive the Digital Output
Note: This request requires the privilege of I/O access control.
Method: GET/POST
Syntax:
http://<servername>/cgi-bin/setdo.cgi?do1=
[&do3=
