Vivotek PT3112 User Manual
Page 2
All specifications are subject to change without notice.
All other trademarks are owned by their respective companies.
6F, No.192, Lien-Cheng Rd., Chung-Ho,Taipei County, Taiwan
Tel: +886 2 82455282
Fax: +886 2 82455532
E-mail: [email protected]
Http://www.vivotek.com
Pan:270
Tilt:135
System
Networking
Video
Camera
Specifications
Lens
Microphone
Models
P an: range +135~ 135 , 10 ~ 50 /sec
T
ilt: range +90 ~ 45 , 7 ~ 25 /sec
A
uto pan mode
A
uto patrol mode
CE
, FCC
Op
eration system: Microsfot Windows98 SE, ME,
2000, XP
B
rowser: Internet Explorer 5.0 or above
R
emote configuration and control sixteen devices
E
vent-triggered, scheduled, manual recording
Instan
t search with preview windows
F ast/slow forward replay and pause
Har
d disk quota warning
Scheduled r
ecord
A VI format export
T emperature: 0~40 C(32~102 F)
Humidit
y: 85% RH
S
ystem power and status indicator
S
ystem activity and Network link indicator
Audio
General I/O
LED Indicators
Dimensions
Power
Pan/Tilt
Weight
Operating
Environments
EMI & Safety
Viewing System
Requirements
Free Bundled
ST3402
Software
PT3117/3127
PT3112/3122
NTSC
Up to 30 frames at 176x120
Up to 30 frames at 352x240
Up to 10 frames at 704x480
PAL
Up to 25 frames at 176x144
Up to 25 frames at 352x288
Up to 10 frames at 704x576
P
rotocols
UPnP, TCP/IP, HTTP, SMTP, FTP, Telnet, NTP,
DNS, DDNSand DHCP
E
thernet
10 baseT or 100 baseT Fast Ethernet
auto negotiation
W
ireless (PT3117/3127)
802.11g wireless LAN
A
lgorithm
MPEG-4(short header mode) for streaming video
JPEG for still image
F eatures
Adjustable image size and quality
Time stamp and text overlay
Three configurable motion detection windows
Flip & mirror
Video output connector
R
esolution
PT3112 NT
SC CCD
PT3122 P AL CCD
PT3117 NT
SC CCD (wireless)
PT3127 P AL CCD (wireless)
1 sensor input max. 12VDC 50mA
1 r
elay output max. 24VDC 1A / 125VAC 0.5A
24k
bps
A
udio output connector
Ex
ternal microphone connector
Supp
orts audio mute
1/4 inch c
olor CCD image sensor
1 L
ux / F2.0
A
GC, AWB, AES
PT3112/PT3117
Resolution: 512(H)x492(V)
Electronic shutter: 1/60~1/100,000 sec.
PT3122/PT3127
Resolution: 512(H)x582(V)
Electronic shutter: 1/50~1/100,000 sec.
4.3mm, F2.0
Omni-dir
ectional
F requency
20 ~ 20000Hz
S/N r
atio
More than 58dB
L
ength: 104mm (Antenna not included)
W
idth: 105mm
H
eight: 114mm
NET : 340g
12VDC
C
onsumption:
PT3112/3122: Max 8W
PT3117/3127: Max 9.2W
CPU: Trimedia PNX1300
R
AM: 16MB SDRAM
R
OM: 2MB FLASH ROM
135
135
90
45
P ower C ord S ocket
E thernet 10/100
R J 45 S ocket
G eneral I/O
T erminal B lock
V ideo Loop O ut and
Audio O ut
W ireles s Antenna
C onnector
E xternal Microphone
Input
