25 104408
OWNER’S MANUAL
PARTS LIST
VMH10TNA
This list contains replaceable parts used in
your fireplace. When ordering parts, follow
the instructions listed under Replacement
Parts on page 26 of this manual.
KEY VMH10TNA
NO. PART NO. DESCRIPTION QTY.
1 102633-02CK Outer Casing Top 1
2 102624-02 Outer Casing 1
3 099230-02 Shoulder Screw 14
4 098304-01 Screw, #10 x 3/8" 12
5 103591-01 Burner 1
6 103209-03 Louvered Door 1
7 102635-02CK Left and Right Side Front 2
8 104058-01 Branch 1
9 103209-01 Brass Top Louver 1
10 101712-04 Firebox Hood 1
11 102638-01 Firebox Top 1
12 103042-01 ODS/Pilot Assembly 1
12-1 098514-01 Thermocouple 1
12-2 098594-01 Ignitor Electrode 1
13 102460-01CJ Firebox Wrapper 1
14 099211-01 Control Bracket Screw 2
15 103963-01 Inlet Tube 1
16 103671-01 Outlet Tube 1
17 100587-01 Brass Screw, #6 x 3/8 4
18 098303-02 Regulator Screw 2
19 104335-01CK Outer Shell Base 1
20 102649-02CJ Branch Support 1
21 099415-10 Gas Regulator 1
22 102875-01 Regulator Bracket 1
23 101381-01 Valve Cover and Piezo 1
24 099387-03 Pilot Tube 1
25 098271-06 Ignitor Cable 1
26 M11084-38 Screw #8 x 3/8 1
27 101004-12 Injector 1
28 098522-14 Gas Valve 1
29 102639-01 Baffle 1
30 101628-01 Flexible Connector 1
31 102869-01 Control Bracket 1
32 102731-01 Control Shield 1
33 103295-01CJ Screen Assembly 1
34 104078-01 Main Log 1
35 104313-01 Hinge Pin (Right) 1
36 104313-02 Hinge Pin (Left) 1
37 M10908-2 Hinge Screws 4
38 103734-01 Burner Support 2
39 101006-01 Pilot Bracket 1
40 097809-03 3/8" NPT x 3/8" Flare Brass Fitting 1
41 098249-01 Nut, M5 2
42 101629-02 Bushing 1
43 M11084-26 Hex Head Screw, #10 x 3/8" 31
44 102458-01CK Middle Rail 1
PARTS AVAILABLE — NOT SHOWN
101054-01 Lighting Instructions Plate 1
100563-01 Warning Plate 1
103470-01 Hardware Package 1
104319-02 Video, Instruction 1
