Vestax PMC 250 - Manual (Page 12)

Vestax Corporation
S P E C I F I C A T I O N S
INPUT
SECTION
MIC 1/4' PHONE JACK -50dBv -20dBv 3.3k
PHONO 1 3L/R RCA PIN JACK -42dBv -22dB v 22k
LINE 1 5L/R RCA PIN JACK -10/0/+6dBv +20dBv 22k
RATED OUTPUT MAXIMUM OUTPUT IMPEDANCE
PA OUT L/R XLR MALE 2PIN HOT,BALANCE 0dBv,-10dBv +19dBv 600 OVER
LINE L/R 1/4' PHONE JACK,UNBALANCE -10dBv +10dBv 2k OVER
BOOTH OUT L/R 1/4" PHONE OUT ) -10dBv +14dBv 600 OVER
HEAD PHONE 1/4" PHONE JACK 130mW 8 OVER/47
MIC 30Hz 20kHz 3dB CROSSFADER CROSSTALK > 100dB
LINE 20Hz 20kHz 1dB CHANNEL CROSSTALK > 65dB
MIC >60dB POWER SUPPLY AC12V ADAPTOR
LINE >75dB DIMENSIONS W H D 482 138 112
>70d B WEIGHT 4kg
OUTPUT
SECTION
FREQUENCY
RESPONSE
S/N RATIO
FADER
ATTENUATION
NOMINAL INPUT
LEVEL
MAXIMUM INPUT
LEVEL
IMPEDANCE
Sep.01 PMC250 E1
