ViewSonic VX715 6
Installation of Wall Mount (Optional)
To obtain a wall-mounting kit, contact ViewSonic or your local dealer. Refer to the instructions
that come with the base mounting kit. To convert your LCD display from a desk-mounted to a
wall-mounted display, do the following:
1. Disconnect Power.
2. Lay the LCD display face down on a towel or blanket.
3. Remove the Plastic Covers from the back of the LCD display.
4. Remove the four screws attaching the base.
5. Remove the Rubber Plugs from inside the four VESA screw holes.
6. Attach the mounting bracket from the VESA compatible wall mounting kit (100 mm x 100
mm distance).
7. Attach the LCD display to the wall, following the instructions in the wall-mounting kit.
Four vesa
screw holes
Plastic
covers
Four base screws
Rear panel
covers
