QuickSpecs
Compaq AlphaStation XP1000
DA-10030 Canada — Version 22 — December 31, 2001 11
Options
Step 10 – AlphaStation XP1000 Rackmount Options (continued)
M-series Cabinet Configuration Chart for AlphaStation XP1000 (5U) with Storage Works shelves (4U)
Cabinet Mounting Kit Cabinet Height / Space System Shelves Ballast Kit
1 6 2
2 5 1
3 4 0
4 2 0
5 1 0 H9A10-MC/MD SN-BA26R-RA − Optional, must
be ordered separately
54.2 ″ / 31U
6 0 0
1 6 2
1 6 2
3 5 0
4 4 0
5 3 0
6 2 0
H9A15-MC/MD SN-BA26R-RA − Optional, must
be ordered separately
66.5 ″ / 38U
7 0 0
M-series Cabinets 67 ″ cabinet enclosure with 54.2 ″ or 33U of usable vertical space; 120V dual-24A controller,
each with 10 NEMA 5-15R outlets, input power plug NEMA L5-30P; includes rear door,
top fan tray, and two H7600-AA power distribution units
H9A10-MC
79 ″ cabinet enclosure with 66.5 ″ or 40U of usable vertical space; 120V dual-24A controller,
each with 10 NEMA 5-15R outlets, input power plug NEMA L5-30P; includes rear door,
top fan tray, and two H7600-AA power distribution units
H9A15-MC
NOTE: For more information on M-series Cabinet Enclosures:
http://www.compaq.com/alphaserver/products/m-series/index.html NOTE: This website is available in English only.
Cabinet Front Door Top gun blue front door for H9A10-MC/MD cabinet H9C10-TF
Top gun blue front door for H9A15-MC/MD cabinet H9C15-TF
StorageWorks UltraSCSI single bus, single-ended shelf with 180W power supply and
RETMA mounting kit
BA36R-RC Shelves supported in M-series
Cabinets with front doors
(H9A10/M9A15)
StorageWorks controller shelf with RETMA mounting kit and NEMA power for H9A10-MC,
H9A15-MC cabinets
BA35R-MR
180W power supply CK-BA35X-HH
Factory Integration Factory Integration of systems and storage devices assembled and configured in cabinet
enclosure for H9A10/H9A15 cabinet enclosures
YS-ASCAA-AA
Ballast Kit • Ballast is dead weight added to a cabinet at specific locations for specific configurations to meet safety
regulations for installation, operation, and service; see “Cabinet Configuration Chart” for ballast kit
requirements
Two 35 to 40 lb steel plates H9C10-MC
NOTE: For more information on M-series Cabinet Enclosures:
http://www.compaq.com/alphaserver/products/m-series/index.html NOTE: This website is available in English only.
Rackmount Power Cords 4.5 m BN20Z-4E
