Custom panel–kitchen cleanup, Dimensions & specifications

background image

17-3/16

(43.7 c

m)

7-1/4”*

(18.4 c

m)

7-1/4”*

(18.4 cm)

28-

1/4”

(71.8 cm)

3/32”

(0.1

cm) dia.

1/4“

(0.6 cm) dee

p

1-5/16”**

(3.3 cm)

1-3/

16”

(3.0 cm)

1-1

5/1

6”

(3.7 cm)

Back of
overlay panel

3/4”

(1.9 cm)

1/16” x 45°

chamfer

CUSTOM PANEL–KITCHEN CLEANUP

Undercounter 18ÓW. Trash Compactor—DFC1 80

P L A N N I N G A N D D E S I G N G U I D E

V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1

R E L E A S E D 1 2 / 1 / 0 7

© 2 0 0 7 V R C — INFORMATION SUBJECT TO CHANGE

Dimensions & Specifications

DFC180

Overall panel width

17-3/16” (43.7 cm)

Overall panel height

28-1/4” (71.8 cm)

Overall panel depth

3/4” (1.9 cm)

Maximum panel weight

25 lbs. (11.4 kg)

CUSTOM PANEL DIMENSIONS

DFC180

*Maximum distance for handle holes from centerline. Holes can be drilled anywhere in between.
**Minimum distance for handle holes from top of overlay panel.

SIDE VIEW
