configuration.
Network Camera will automatically detect and operate in the available network
interface with the priority of Ethernet than WLAN. Operating in either network mode,
the LED will flash every second as heartbeat to indicate alive.
Network Camera provides a general I/O terminal block with one digital input and one
relay switch for device control. Pin 1 and pin 2 can be connected to an external sensor
and the state of voltage will be monitored from the initial state 'LOW'. The relay switch
of pin 3 and pin 4 can be used to turn on or off the external device.
1 DI-
INPUT (Initial state of DI is low)
2 DI+
INPUT (Max. 50mA, 12VDC)
3 SW_COMMON
OUTPUT (open from SW_OPEN at initial state)
(close with SW_OPEN when set DO to ON)
4 SW_NOPEN
OUTPUT (Max. 1A, 24VDC or 0.5A, 125VAC)
Consult with the dealer of the peripherals for correct installation.
