OPERATING INSTRUCTIONS

SR-F1B
SR-L1B

SPEAKER SYSTEM
SUPER WOOFER SYSTEM

Note: The SR-F1B comes with two nuts on the bottom side, which

are used only for mounting the SR-F1B to an optional
speaker stand. Never use these nuts for speaker suspension.

SR-F1B

Electronic-controlled system (bi-amplifier driven system) with the AC-F1 Electronic Control Unit.

High power capacity of 120 watts continuous pink noise for low frequency and 80 watts for high frequency.

High-efficiency 30 cm (12") woofer using a 20 cm (8") large magnet.

HFD-651 type high power driver with LE Series Constant Directivity(CD) Horn (60° horizontal by 40° vertical).

Fixing metals for suspension provided on top and bottom sides of the enclosure.

Provided an angle of 15° at both sides of the enclosure to prevent mutual interference in high frequency range.

SR-L1B

Electronic-controlled system with the AC-L1 Electronic Control Unit.

High power capacity of 300 watts continuous pink noise.

Ultra-linear, high power 38cm (15") woofer.

General Features

Neutrik NL4MPR input connector.

APITON plywood enclosure with rugged FRP coating.

Removable punched metal front grill.

TOA Corporation

FEATURES

SR-F1B

SR-L1B
