- 12 -
KEY
PART
No.
No.
DESCRIPTION
QTY.
1
SV13296 A
DAPTER
/D
AMPER
1
2
SV15434 R
OCKER SWITCH WHITE
(
PAIR
) +
OVERLAY WHITE
1
SV15433 R
OCKER SWITCH BLACK
(
PAIR
) +
OVERLAY BLACK
1
3
SV03623 F
LUORESCENT LAMP
2
4
SV01752 L
IGHT DIFFUSER
1
5
SV01765 M
OTOR
1
6
SV01988 B
LOWER WHEEL
1
7
SV16119 B
OTTOM PAN WHITE
1
SV16117 B
OTTOM PAN BLACK
1
8
SV01757 I
NLET RING
1
9
SV14131 M
ICROMESH FILTER
(
THE PAIR
)
1
10
SV02104 S
ECONDARY CAPACITOR
7.5 µ
F
1
11
SV06756 C
APACITOR
11.5 µ
F
1
12
SV03649 B
ALLAST HARNESS
(
SOCKET LAMPS INCLUDED
)
1
*
SV06727 I
NSTALLATION
&
USER MANUAL
1
*
SV04281
H
ARDWARE BAG
: (1)
WIRE CLAMP
, (2)
WIRE CONNECTORS
1
(6)
NO
. 6
X
1/2”
SCREWS
, (5)
NO
. 8
X
1/2”
DOUBLE THREAD SCREWS
12. SERVICE PARTS
HL0095
*Not shown
MODEL QDE
1
2
3
4
5
6
7
8
9
10
12
11
