CHARACTERISTICS ONE SECTION TWO SECTION
Width, Overall 26 1 /
2
52 1 /
8
Depth, Overall (incl. handles) 29 7 / 8
29 7 / 8
Height, Overall (incl. adj. legs) 84 84
Total Capacity of Drawers (cubic Feet) 4 8
No. of Drawers 4 8
Drawer Pan - Width 14 3 / 4
14 3 / 4
Drawer Pan - Depth 19 3 /
4
19 3 /
4
Drawer Pan - Height 6 6
Cabinet Voltage 115/60/1 115/60/1
Feed Wires 2 2
Condensing Unit Voltage 115/60/1 115/60/1
Condensing Unit Size (HP) 1 /
4
1 /
3
Total Amperes 8.0 11.3
Victory participates in the KCL CADalog, the most current source of CAD symbols for foodservice designers worldwide. Symbols include
standard equipment in plan, side, front and 3-D views, layered for FEDA/FCSI recommended guidelines.
Continuous product development may necessitate specification changes and design without notice.
Victory Refrigeration, Inc. Shallow Depth Fish File Refrigerators
Crated dim. & wts. Ht. Width Depth Cu.Ft. Lbs
One Section 82 36 1 / 2 44 3 / 4 77.5 565
Two Section 87 63 5 /
8
44 3 /
4
135.1 845
FOR REMOTE MODELS– Substitute an “R” for the “S” in suffix. For
example: Model RS-1N-S7-FF (self-contained) would be RS-1N-R7-FF
remote cabinet. Air circulating fans, expansion valve and plasticized
coil are provided. Condensing units not supplied. The following units
are recommended with
1 / 2 ” O.D. Suction line, 1 / 4 ” O.D. Liquid line.
Dimensional tolerance ± 1 / 4 ” Metric dimensions (MM)
REMOTE REFRIGERATION
Cond. Unit BTUH Cabinet Amps
One Section 1 / 4 H.P. 2030 115/60/1 2.5
Two Section 1 /
3
H.P. 2540 115/60/1 3.4
Copyright June 2009
Printed in U.S.A. 063009
29.88
(758)
22.50
(571)
19.75
(502)
9.62
(245)
TYP OPN'G
13.12
(333)
26.38
(670)
28.38
(720)
6.00
(152)
DRAWER PAN
14.12
(358)
21.12
(537)
TYP OPN'G
13.25
(336)
6.00
(152)
26.50
(660)
84.00
(2133)
TOP VIEW TOP VIEW
FRONT VIEW FRONT VIEW SIDE VIEW
CORD & PLUG
1.00" (25) NPT WASTE DRAIN
CONNECTION TO FLOOR DRAIN
INTERIOR COIL
48.12
(1222)
29.88
(758)
84.00
(2133)
6.00
(152)
21.12
(537)
TYP OPN'G
52.13
(1324)
26.06
(662)
CORD & PLUG
1.00" (25) NPT WASTE DRAIN
CONNECTION TO FLOOR DRAIN
INTERIOR COIL
NOTE: If cabinet is located
directly against wall an all
around clearance of 2” is
required, and a minimum
clearance of 10” under
ceiling.
We reserve the right to
change specifications and
product design without
notice. Such revisions do
not entitle the buyer to
corresponding changes,
improvements, additions or
replacements for previously
purchased equipment.
