9
© 2006 Directed Electronics—all rights reserved
Button
Controls the system L Loocckk function by pressing this button for
one second.
Button
Controls the system U Un nlloocckk function by pressing this button for
one second.
Button
Controls an optional A Au uxxiilliiaarryy function, such as trunk release by
pressing this button for 1.5 seconds.
The auxiliary output controls __________________________.
Button
Controls Remote Start feature by pressing this button two times.
and Buttons
Controls and optional auxiliary channel output for a convenience
or expansion feature that has been added to your system. This
feature is operated by pressing these buttons simultaneously.
The auxiliary output controls __________________________.
and and Buttons
When simultaneously pressed these buttons control the rear
window defogger during remote starting.
Standard Button Configurations
