The base unit layout – VTech i 5836 User Manual
Page 8
1
2
10
3
5
6
7
8
4
9
11
12
13
14
6
1. Antenna
2. LCD Display
3. Clear
4. In Use
5. Flash
6. Hold
7. Redial
8. Mute
9. Message LED
The Base Unit Layout
10. Intercom
11. Softkeys
12. Speaker Phone
13. Dialing Keys (0-9,
*
, #)
14. Volume Keys
15. Telephone Jack
16. DC Connector
17. Spare Battery Drawer
18. Spare Battery Release Button
i 5886 manualNov11.p65
11/12/2003, 9:50 AM
6
