2.3.4 Using the Device
The usage mode is set by sliding the window up or down before
connecting to your PC.
• To use the UM150 as both a modem and mass storage device, slide the
window up and insert the UM150 into a PC USB port. To use it as a mass
storage device only, slide the window down and insert the UM150 into a PC
USB port.
Note: Make sure to complete the unplugging/ejection process before
removing the UM150. If you remove the device improperly, the product may
be damaged.
Function Operation LED Status
Modem
and
Mass
storage
Slide the window up
➡
Insert to PC USB port
➊ OFF
➋ ON (Blue light level
shows signal strength)
➌ ON (Blue light blinks)
Slide the window up
➡
Insert to PC USB port
➡ Slide the window down
➊ ON (Blue light blinks)
➋ OFF
➌ OFF
Mass
storage
only Slide the window down
➡
Insert to PC USB port
➊ ON (Blue light stays on)
➋ OFF
➌ OFF
Slide the window down
➡
Insert to PC USB port
➡ Slide the window up
➊ OFF
➋ OFF
➌ ON (Blue light stays on)
Note: For a computer with no VZW Access Manager installed, to use UM150
as a mass storage device only, slide the window down and insert it into a PC
USB port.
6
UM150 User’s Manual
Window slide
up condition
 Mass storage indicator
(disabled)
 Signal strength indicator
(enabled)
 Power status LED
(enabled)
Window slide
down condition
 Mass storage indicator
(enabled)
 Signal strength indicator
(disabled)
 Power status LED
(disabled)
