United States Stove Company C9947N - Manual (Page 23)

CONTROL
WIRING
TERMINALS
ROCKER
SWITCH
THERMOPILE
WIRING DIAGRAM FOR GENERATOR ASSEMBLY
WIRING DIAGRAM FOR BLOWER ASSEMBLY
1/4" MALE INS.
1/4" FEMALE
INS.
1/4"FEMALE INS.
1/4"FEMALE INS.
1/4"FEMALE INS.
1/4" MALE INS.
1/4" MALE INS.
1/4"FEMALE INS.
BLACK
BLACK
WHITE
(NEUTRAL)
BLACK
(HOT)
GREEN
(GROUND)
RHEOSTAT
THERMODISC
BLOWER
80425 (28")
80426 (12")
23
