Uniden BC92XLT User Manual
Owner’s manual
Table of contents
Document Outline
- Precautions
- BC92XLT Controls and Display
- Contents
- The FCC Wants You To Know
- Introduction
- Feature Highlights
- Understanding Scanning
- Included With Your Scanner
- Setting Up Your Scanner
- Using Internal Batteries
- 1. Make sure the power is turned off.
- 2. Slide the battery compartment cover.
- 3. Before you install alkaline or any other non- rechargeable batteries, use a pointed object such as a ballpoint pen to set REG. ALK. BATT./ NI-MH BATT. inside the compartment to REG. ALK. BATT..
- 4. Install two batteries in the compartment as indicated by the polarity symbols (+ and -) marked inside.
- 5. Replace the cover.
- 6. When flashes and the scanner beeps every 15 seconds, replace both batteries.
- Using AC Power
- Connecting the Antenna
- Connecting an Earphone/Headphone
- Connecting an Extension Speaker
- Attaching the Belt Clip
- Using Internal Batteries
- About Your Scanner
- Operation
- Turning On The Scanner and Setting Squelch
- Storing Known Frequencies Into Channels
- 1. Press Hold. Then enter the channel number where you want to store a frequency, then press Func and Pgm. The channel number appears.
- 2. Use the number keys and to enter the frequency (including the decimal point) you want to store.
- 3. Press E to store the frequency into the channel.
- 4. To program the next channel in sequence, press E then repeat Steps 2 and 3.
- Searching For and Temporarily Storing Active Frequencies
- 1. Press Func and Pgm during service search or service search hold mode. The frequency and the lowest blank channel alternately appear.
- 2. Press E to store the frequency into the blank channel. If you want to select another channel, press Func + or Func + before you press E. You can also use the 0-9 key to select the bank.
- Scanning the Stored Channels
- Manually Selecting a Channel
- Special Features
- Close CallTM RF Capture Technology
- 1. Press Func then press and hold for 2 seconds. One of the following Close Call options appears.
- 2. Repeatedly press or to select the option you want, then press E.
- 3. Repeatedly press or until the band you want to search appears, then press E to select it. Otherwise, press if you do not want to select it.
- 4. Repeatedly press or until the option you want appears, then press E to select it. Otherwise, press if you do not want to select it. Then skip to Step 9.
- 5. Press E while C-C.Alt appears. One of the following alert options appears.
- 6. Repeatedly press or until the option you want appears, then press E to select it. Otherwise, press if you do not want to select it. Then skip to Step 9.
- 7. Press E while C-C.PS appears. One of the following Pager Screen options appears.
- 8. Repeatedly press or until the option you want appears, then press E to select it.
- 9. When you select the option, press Scan to start Close Call search. Otherwise, to continue normal scanning, repeatedly press Func until disappears then press Scan.
- Chain Search
- 1. Press Func + Pgm in chain search mode or chain search hold mode. The lowest blank channel and bank appear.
- 2. Press E to store the frequency into the blank channel. To select another channel, press Func + or Func + before you press E. You can also press 0-9 to select the bank.
- 1. Enter the lower limit frequency by using the 0-9 and . keys.
- 2. Press E to select the lower limit frequency.
- 3. Enter the upper limit frequency by using the 0-9 and keys.
- 4. Press E to select the upper limit frequency.
- Direct Entry Search
- 1. If the scanner is scanning or searching, press Hold.
- 2. Enter the frequency you want to start from by using the number keys. (Press to enter a decimal point).
- 3. Press Func + or Func + . The scanner searches, starting from the frequency you entered in Step 2.
- 1. Press Func + Pgm in direct entry search mode or direct entry search hold mode. The frequency and lowest blank channel alternate on the display.
- 2. Press E to store the frequency into the blank channel. To select another channel, repeatedly press Func + or Func + to select the blank channel you want, then press E. You can also use the 0-9 keys to select the bank.
- Search Skip Memory
- Delay
- Turning Channel-Storage Banks On and Off
- Locking Out Channels
- Priority
- Using Keylock
- Using the Display Backlight
- Close CallTM RF Capture Technology
- Troubleshooting
- Care and Maintenance
- Specifications
- Optional Accessories
- One-Year Limited Warranty
