Standard View Mode
Menu Mode
Quad View Mode
3)
View Next Camera (CH1-4)
Cursor Up
Hot Key CH 1
4)
Volume Down
Cursor Left
Hot Key CH 2
5)
Lullaby Play Switch
Cursor Down
Hot Key CH 3
6)
Volume Up
Cursor Right
Hot Key CH 4
7)
Enter Menu Mode
ESC (back)
8)
Manual Record
Delete Record File
9)
Push to Talk
OK (confirm)
10)
Power Button
Press to turn power ON, press and hold for 2 seconds to turn power OFF.
Step 3: Advanced Operation
I. Get to Know the Display Icons
a.
Signal Indicator
f.
VOX
VOX ON
b.
Current Channel Indicator
g.
VOX Alarm ON
c.
SD Card
h.
Battery Low Indicator (Cam)
- available
i.
Push to talk Indicator
- locked
j.
System Time
- full (flashing)
k.
3
Volume Bar
- error (flashing)
d.
Record indicator (flashing)
#
Volume bar is green when camera lullaby
volume is adjusted.
e.
Lullaby Play Indicator
#
Volume bar is blue when monitor volume
is adjusted.
Lullaby Mute Indicator
a b c d e f g h
i
j
VOX
k
3
